The station
equipment
Main Tranciever in my shack.
The FT-950, the newest radio in the direct lineage of the FTDX-9000 and FT-2000 series radios, has been developed to fit the needs of both casual and serious DX enthusiasts, as well as new HF licensees eagerly seeking to discover the magic of the HF and 50MHz bands.  Prospective owners will find that this radio comes in an appropriately-sized desktop package that provides them with loads of easily located controls and features to ensure they enjoy all of the excitement available on the 160 through 6 meter Amateur Radio bands.
The VX-6R is an ultra-rugged 144-430 MHz FM Hand-Held featuring wide receiver coverage, JIS7 submersibility, the Yaesu-exclusive Emergency Automatic Identification (EAI) system, and ultra-simple keyboard access to important features.

New on the VX-6R is the One-Touch Direct Memory Recall feature, that allows you to recall ten favorite memories with a single button press, just like on your car stereo.

The VX-6R comes equipped with a high-capacity 1400 mAh Lithium-Ion Battery Pack.
VX-6 Portofoon
Standard (Yaesu) C-508
Country                        :          Japan
Manufacturer/Brand :         Standard Radio (SR), Tokyo
Year                              :         1995
Type                              :        Amateur Transmitter/Receiver (and Transceiver)
Principle        Superhet, double/triple conversion; IF-Freq 23050/450 kHz
Wave bands        Wave Bands given in the notes.
Power type and voltage        Batteries (storage and/or dry) / 2 × 1,5 Volt
Loudspeaker        Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out        0.1 W
from Radiomuseum.org        Model: C-508
Material        Modern plastics (no Bakelite or Catalin)
Shape        Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD)        64 x 95 x 29 mm / 2.5 x 3.7 x 1.1 inch
Notes        STANDARD VHF/UHF-FM-Handfunkgerät C-508.
Frequenzbereich: 144···146 MHz und 430···440 MHz (erweiterbar); Pout 280 mW; 60 Speicherkanäle, 1750-Hz-Rufton.
Yaesu FT-817 QRP portable tranciever
FT-817 The Ultimate Backpacker!
Multi-mode Portable Transceiver

The world’s first self-contained, battery-powered, Multi-mode Portable Transceiver covering the HF, VHF, and UHF bands!

For more than four decades, Yaesu has been a world leader in the design and manufacture of high-performance multi-mode base station and mobile transceivers, as well as FM handhelds.Yaesu broke new ground with the introduction of the FT-817: the world’s first HF/VHF/UHF self-contained battery-powered Multi-mode Portable Transceiver. Providing up to five watts of power output, the FT-817 is designed for operation on the 160-10 meter HF bands, plus the 6 meter, 2 meter, and 70 cm bands. Whether your preferred operating mode is SSB, CW, AM, FM, Packet, or SSB-based Digital modes like PSK31, the FT-817 is ready to join you on your next hiking, camping, or search-and-rescue adventure!
Type: Regulated power supply
Output voltage: 1-15 VDC
Output current: 30 A (100% duty cycle)
Dimensions (W*H*D): 250*150*240 mm
Weight: 9 Kg
Manufactured: 199x-xxxx
Other: Cigarette lighter socket (15 A). Automatic cooling fan.
DIAMOND GSV3000 1-15V 30AMPERE VOEDING
The LDG Z-817 is the ultimate autotuner for QRP radios including the Yaesu FT-817(D). The Z-817 interfaces to the CAT port (ACC) on the back of the FT-817 radio with the provided cable. Tuning could not be simpler; one button push on the tuner is all that is needed and the Z-817 takes care of the rest. It will switch to PKT mode, transmit a carrier, tune the tuner, then restore the radio to the previous mode! 2000 memories cover 160 through 6 meters.

Of course, the Z-817 will also function as a general purpose antenna tuner with other QRP radios. Just transmit a carrier and press the tune button on the tuner. The Z-817 is powered by four AA internal Alkaline batteries (not included), so there are no additional cables required to use the Z-817. A coax jumper cable is also included for fast hook up. Latching relays are used so that power consumption is Zero when not tuning allowing a set of batteries to last about one year. Includes 1 foot CAT cable and 1 foot coax jumper.

Specifications:
* Continuous coverage 1.8 to 54 MHz
* Power rating (1.8 to 54 MHz): 0.1 to 20 watts
* Latching relays for ultra low power consumption
* Tuning time: 0.5 to 6 seconds, 3 seconds average
* Antenna impedance: 6 to 600 ohms (about 10:1 SWR range). 16 to 150 on 6M (about 3:1)
* 2000 memories with FT-817 (200 with other radios)
* Power requirements: four AA cells
* Enclosure: 5.5 x 5.25 x 1.5 inches 9.3 oz (without AA cells)
Tuner Z817
FT-726R
All-mode VHF/UHF tri-band transceiver. Verwisselbare plug-in RF-module voor elke band, 10 Watt output, SSB processor, crossband mogelijkheid voor satelliet QSO, twee multi-mode analoge meters, FM center tuning indicator, PBT, IF-shift, clarifier, noise blanker, selecteerbare AGC, dual VFO, 11 geheugens, scannen, dual-watch, programmeerbare repeater shift. Idee in Japan, jaar van introductie 1983.
